results
| P/N | Displacement (cm3/min) | Tank capacity (kg) | Low level monitoring | Gearbox ratio | Power supply | Power cable | Pressure switch | 控制器 | Signal cable | Outlet thread | H (mm) | W (mm) | L (mm) | Ød1 (mm) | Ød2 (mm) | Ød3 (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| HXP55EHD | 444 | 55 | Electric level sensor | / | Hydraulic oil | / | / | / | / | G 1/4 | 1045 | 572 | 457 | 425 | 394 | 4 x Ø15 |
| HXP55LHD | 444 | 55 | Visual indicator | / | Hydraulic oil | / | / | / | / | G 1/4 | 1045 | 572 | 457 | 425 | 394 | 4x Ø15 |
| HXP40EHD | 444 | 40 | Electric level sensor | / | Hydraulic oil | / | / | / | / | G 1/4 | 1045 | 552 | 437 | 385 | 352 | 6 x Ø11 |
| HXP40LHD | 444 | 40 | Visual indicator | / | Hydraulic oil | / | / | / | / | G 1/4 | 1045 | 552 | 435 | 385 | 352 | 6 x Ø11 |
| HXP28EHD | 444 | 28 | Electric level sensor | / | Hydraulic oil | / | / | / | / | G 1/4 | 845 | 551 | 437 | 385 | 352 | 6 x Ø11 |
| HXP28LHD | 444 | 28 | Visual indicator | / | Hydraulic oil | / | / | / | / | G 1/4 | 845 | 552 | 437 | 385 | 352 | 6 x Ø11 |
| HXP55EPSCHR1D24 | 88 | 55 | Electric level sensor | 24:1 | DC 24V | / | Yes | Yes (Hour) | / | G 1/4 | 920 | 470 | 552 | 425 | 394 | 4x Ø15 |
| HXP55EPSCMR1D24 | 88 | 55 | Electric level sensor | 24:1 | DC 24V | / | Yes | Yes (Minute) | / | G 1/4 | 920 | 470 | 552 | 425 | 394 | 4x Ø15 |
| HXP55ECMR1D24 | 88 | 55 | Electric level sensor | 24:1 | DC 24V | / | / | Yes (Minute) | / | G 1/4 | 920 | 470 | 552 | 425 | 394 | 4x Ø15 |
| HXP55ECHR1D24 | 88 | 55 | Electric level sensor | 24:1 | DC 24V | / | / | Yes (Hour) | / | G 1/4 | 920 | 470 | 550 | 425 | 394 | 4x Ø15 |
| HXP55EPSR1D24 | 88 | 55 | Electric level sensor | 24:1 | DC 24V | / | Yes | / | / | G 1/4 | 920 | 470 | - | 425 | 352 | 6x Ø11 |
| HXP55ER1D24 | 88 | 55 | Electric level sensor | 24:1 | DC 24V | / | / | / | / | G 1/4 | 920 | 470 | - | 425 | 394 | 6x Ø11 |
| HXP55LPSCMR1D24 | 88 | 55 | Visual indicator | 24:1 | DC 24V | / | Yes | Yes (Minute) | / | G 1/4 | 920 | 470 | 552 | 425 | 394 | 4x Ø15 |
| HXP55LPSCHR1D24 | 88 | 55 | Visual indicator | 24:1 | DC 24V | / | Yes | Yes (Hour) | / | G 1/4 | 920 | 470 | 552 | 425 | 394 | 4x Ø15 |
| HXP55LCMR1D24 | 88 | 55 | Visual indicator | 24:1 | DC 24V | / | / | Yes (Minute) | / | G 1/4 | 920 | 470 | 552 | 425 | 394 | 4x Ø15 |
| HXP55LCHR1D24 | 88 | 55 | Visual indicator | 24:1 | DC 24V | / | / | Yes (Hour) | / | G 1/4 | 920 | 470 | 552 | 425 | 394 | 4x Ø15 |
| HXP55LPSR1D24 | 88 | 55 | Visual indicator | 24:1 | DC 24V | / | Yes | / | / | G 1/4 | 920 | 470 | - | 425 | 394 | 6x Ø11 |
| HXP55LR1D24 | 88 | 55 | Visual indicator | 24:1 | DC 24V | / | / | / | / | G 1/4 | 920 | 470 | - | 425 | 352 | 6x Ø11 |
| HXP40EPSCMR1D24 | 88 | 40 | Electric level sensor | 24:1 | DC 24V | / | Yes | Yes (Minute) | / | G 1/4 | 920 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP40EPSCHR1D24 | 88 | 40 | Electric level sensor | 24:1 | DC 24V | / | Yes | Yes (Hour) | / | G 1/4 | 920 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP40ECMR1D24 | 88 | 40 | Electric level sensor | 24:1 | DC 24V | / | / | Yes (Minute) | / | G 1/4 | 920 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP40ECHR1D24 | 88 | 40 | Electric level sensor | 24:1 | DC 24V | / | / | Yes (Hour) | / | G 1/4 | 920 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP40EPSR1D24 | 88 | 40 | Electric level sensor | 24:1 | DC 24V | / | Yes | / | / | G 1/4 | 920 | 443 | - | 385 | 352 | 6 x Ø11 |
| HXP40ER1D24 | 88 | 40 | Electric level sensor | 24:1 | DC 24V | / | / | / | / | G 1/4 | 920 | 445 | - | 385 | 352 | 6 x Ø11 |
| HXP40LPSCHR1D24 | 88 | 40 | Visual indicator | 24:1 | DC 24V | / | Yes | Yes (Hour) | / | G 1/4 | 920 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP40LPSCMR1D24 | 88 | 40 | Visual indicator | 24:1 | DC 24V | / | Yes | Yes (Minute) | / | G 1/4 | 920 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP40LCMR1D24 | 88 | 40 | Visual indicator | 24:1 | DC 24V | / | / | Yes (Minute) | / | G 1/4 | 920 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP40LCHR1D24 | 88 | 40 | Visual indicator | 24:1 | DC 24V | / | / | Yes (Hour) | / | G 1/4 | 920 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP40LPSR1D24 | 88 | 40 | Visual indicator | 24:1 | DC 24V | / | Yes | / | / | G 1/4 | 920 | 445 | - | 385 | 352 | 6 x Ø11 |
| HXP40LR1D24 | 88 | 40 | Visual indicator | 24:1 | DC 24V | / | / | / | / | G 1/4 | 920 | 443 | - | 385 | 352 | 6 x Ø11 |
| HXP28EPSCMR1D24 | 88 | 28 | Electric level sensor | 24:1 | DC 24V | / | Yes | Yes (Minute) | / | G 1/4 | 720 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP28EPSCHR1D24 | 88 | 28 | Electric level sensor | 24:1 | DC 24V | / | Yes | Yes (Hour) | / | G 1/4 | 720 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP28ECMR1D24 | 88 | 28 | Electric level sensor | 24:1 | DC 24V | / | / | Yes (Minute) | / | G 1/4 | 720 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP28ECHR1D24 | 88 | 28 | Electric level sensor | 24:1 | DC 24V | / | / | Yes (Hour) | / | G 1/4 | 720 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP28EPSR1D24 | 88 | 28 | Electric level sensor | 24:1 | DC 24V | / | Yes | / | / | G 1/4 | 720 | 445 | - | 385 | 352 | 6 x Ø11 |
| HXP28ER1D24 | 88 | 28 | Electric level sensor | 24:1 | DC 24V | / | / | / | / | G 1/4 | 720 | 445 | - | 385 | 352 | 6 x Ø11 |
| HXP28LPSCHR1D24 | 88 | 28 | Visual indicator | 24:1 | DC 24V | / | Yes | Yes (Hour) | / | G 1/4 | 720 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP28LPSCMR1D24 | 88 | 28 | Visual indicator | 24:1 | DC 24V | / | Yes | Yes (Minute) | / | G 1/4 | 720 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP28LCMR1D24 | 88 | 28 | Visual indicator | 24:1 | DC 24V | / | / | Yes (Minute) | / | G 1/4 | 720 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP28LCHR1D24 | 88 | 28 | Visual indicator | 24:1 | DC 24V | / | / | Yes (Hour) | / | G 1/4 | 720 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP28LPSR1D24 | 88 | 28 | Visual indicator | 24:1 | DC 24V | / | Yes | / | / | G 1/4 | 720 | 445 | - | 385 | 352 | 6 x Ø11 |
| HXP28LR1D24 | 88 | 28 | Visual indicator | 24:1 | DC 24V | / | / | / | / | G 1/4 | 720 | 445 | - | 385 | 352 | 6 x Ø11 |
