results
| P/N | Tank capacity (L) | Pump type | Low level monitoring | Pump element | 控制器 | Power supply | Pump outlet | H (mm) | W (mm) | L (mm) | K (mm) | E (mm) | Ød (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| LEP2110DTGLCH..A23 | 10 | DT | yes | 2x 6.0 ml/min | Yes (Hour) | AC 230V/50Hz | 2XG 1/4 | 580 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP2110DTGLCM..A23 | 10 | DT | yes | 2x 6.0 ml/min | Yes (Minute) | AC 230V/50Hz | 2XG 1/4 | 580 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP2110DTGNCH..A23 | 10 | DT | / | 2x 6.0 ml/min | Yes (Hour) | AC 230V/50Hz | 2XG 1/4 | 580 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP2110DTGNCM..A23 | 10 | DT | / | 2x 6.0 ml/min | Yes (Minute) | AC 230V/50Hz | 2XG 1/4 | 580 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP2110DGLCM..A23 | 10 | D | yes | 2x 6.0 ml/min | Yes (Minute) | AC 230V/50Hz | 2XG 1/4 | 560 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP2110DGLCH..A23 | 10 | D | yes | 2x 6.0 ml/min | Yes (Hour) | AC 230V/50Hz | 2XG 1/4 | 560 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP2110DGNCH..A23 | 10 | D | / | 2x 6.0 ml/min | Yes (Hour) | AC 230V/50Hz | 2XG 1/4 | 560 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP2110DGNCM..A23 | 10 | D | / | 2x 6.0 ml/min | Yes (Minute) | AC 230V/50Hz | 2XG 1/4 | 560 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP213DTGLCM..A23 | 8 | DT | yes | 2x 6.0 ml/min | Yes (Minute) | AC 230V/50Hz | 2XG 1/4 | 550 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP213DTGLCH..A23 | 8 | DT | yes | 2x 6.0 ml/min | Yes (Hour) | AC 230V/50Hz | 2XG 1/4 | 550 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP213DTGNCM..A23 | 8 | DT | / | 2x 6.0 ml/min | Yes (Minute) | AC 230V/50Hz | 2XG 1/4 | 550 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP213DTGNCH..A23 | 8 | DT | / | 2x 6.0 ml/min | Yes (Hour) | AC 230V/50Hz | 2XG 1/4 | 550 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP213DGLCM..A23 | 8 | D | yes | 2x 6.0 ml/min | Yes (Minute) | AC 230V/50Hz | 2XG 1/4 | 530 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP213DGLCH..A23 | 8 | D | yes | 2x 6.0 ml/min | Yes (Hour) | AC 230V/50Hz | 2XG 1/4 | 530 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP213DGNCM..A23 | 8 | D | / | 2x 6.0 ml/min | Yes (Minute) | AC 230V/50Hz | 2XG 1/4 | 530 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP213DGNCH..A23 | 8 | D | / | 2x 6.0 ml/min | Yes (Hour) | AC 230V/50Hz | 2XG 1/4 | 530 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212PDTGLCH..A23 | 6 | DT | yes | 2x 6.0 ml/min | Yes (Hour) | AC 230V/50Hz | 2XG 1/4 | 540 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212PDTGLCM..A23 | 6 | DT | yes | 2x 6.0 ml/min | Yes (Minute) | AC 230V/50Hz | 2XG 1/4 | 540 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212PDTGNCM..A23 | 6 | DT | / | 2x 6.0 ml/min | Yes (Minute) | AC 230V/50Hz | 2XG 1/4 | 540 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212PDTGNCH..A23 | 6 | DT | / | 2x 6.0 ml/min | Yes (Hour) | AC 230V/50Hz | 2XG 1/4 | 540 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212PDGLCM..A23 | 6 | D | yes | 2x 6.0 ml/min | Yes (Minute) | AC 230V/50Hz | 2XG 1/4 | 520 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212PDGLCH..A23 | 6 | D | yes | 2x 6.0 ml/min | Yes (Hour) | AC 230V/50Hz | 2XG 1/4 | 520 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212PDGNCM..A23 | 6 | D | / | 2x 6.0 ml/min | Yes (Minute) | AC 230V/50Hz | 2XG 1/4 | 520 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212PDGNCH..A23 | 6 | D | / | 2x 6.0 ml/min | Yes (Hour) | AC 230V/50Hz | 2XG 1/4 | 520 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212DTGLCH..A23 | 4 | DT | yes | 2x 6.0 ml/min | Yes (Hour) | AC 230V/50Hz | 2XG 1/4 | 450 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212DTGLCM..A23 | 4 | DT | yes | 2x 6.0 ml/min | Yes (Minute) | AC 230V/50Hz | 2XG 1/4 | 450 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212DTGNCM..A23 | 4 | DT | / | 2x 6.0 ml/min | Yes (Minute) | AC 230V/50Hz | 2XG 1/4 | 450 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212DTGNCH..A23 | 4 | DT | / | 2x 6.0 ml/min | Yes (Hour) | AC 230V/50Hz | 2XG 1/4 | 450 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212DGLCH..A23 | 4 | D | yes | 2x 6.0 ml/min | Yes (Hour) | AC 230V/50Hz | 2XG 1/4 | 430 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212DGLCM..A23 | 4 | D | yes | 2x 6.0 ml/min | Yes (Minute) | AC 230V/50Hz | 2XG 1/4 | 430 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212DGNCM..A23 | 4 | D | / | 2x 6.0 ml/min | Yes (Minute) | AC 230V/50Hz | 2XG 1/4 | 430 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212DGNCH..A23 | 4 | D | / | 2x 6.0 ml/min | Yes (Hour) | AC 230V/50Hz | 2XG 1/4 | 430 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212DTGLCH..D24 | 4 | DT | yes | 2x 6.0 ml/min | Yes (Hour) | DC 24V | 2XG 1/4 | 450 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212DTGLCM..D24 | 4 | DT | yes | 2x 6.0 ml/min | Yes (Minute) | DC 24V | 2XG 1/4 | 450 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212DTGNCM..D24 | 4 | DT | / | 2x 6.0 ml/min | Yes (Minute) | DC 24V | 2XG 1/4 | 450 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP2110DTGLCH..D24 | 10 | DT | yes | 2x 6.0 ml/min | Yes (Hour) | DC 24V | 2XG 1/4 | 580 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP2110DTGLCM..D24 | 10 | DT | yes | 2x 6.0 ml/min | Yes (Minute) | DC 24V | 2XG 1/4 | 580 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP2110DTGNCH..D24 | 10 | DT | / | 2x 6.0 ml/min | Yes (Hour) | DC 24V | 2XG 1/4 | 580 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP2110DTGNCM..D24 | 10 | DT | / | 2x 6.0 ml/min | Yes (Minute) | DC 24V | 2XG 1/4 | 580 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP2110DGLCM..D24 | 10 | D | yes | 2x 6.0 ml/min | Yes (Minute) | DC 24V | 2XG 1/4 | 560 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP2110DGLCH..D24 | 10 | D | yes | 2x 6.0 ml/min | Yes (Hour) | DC 24V | 2XG 1/4 | 560 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP2110DGNCH..D24 | 10 | D | / | 2x 6.0 ml/min | Yes (Hour) | DC 24V | 2XG 1/4 | 560 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP2110DGNCM..D24 | 10 | D | / | 2x 6.0 ml/min | Yes (Minute) | DC 24V | 2XG 1/4 | 560 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP213DTGLCM..D24 | 8 | DT | yes | 2x 6.0 ml/min | Yes (Minute) | DC 24V | 2XG 1/4 | 550 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP213DTGLCH..D24 | 8 | DT | yes | 2x 6.0 ml/min | Yes (Hour) | DC 24V | 2XG 1/4 | 550 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP213DTGNCM..D24 | 8 | DT | / | 2x 6.0 ml/min | Yes (Minute) | DC 24V | 2XG 1/4 | 550 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP213DTGNCH..D24 | 8 | DT | / | 2x 6.0 ml/min | Yes (Hour) | DC 24V | 2XG 1/4 | 550 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP213DGLCM..D24 | 8 | D | yes | 2x 6.0 ml/min | Yes (Minute) | DC 24V | 2XG 1/4 | 530 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP213DGLCH..D24 | 8 | D | yes | 2x 6.0 ml/min | Yes (Hour) | DC 24V | 2XG 1/4 | 530 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP213DGNCM..D24 | 8 | D | / | 2x 6.0 ml/min | Yes (Minute) | DC 24V | 2XG 1/4 | 530 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP213DGNCH..D24 | 8 | D | / | 2x 6.0 ml/min | Yes (Hour) | DC 24V | 2XG 1/4 | 530 | 255 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212PDTGLCH..D24 | 6 | DT | yes | 2x 6.0 ml/min | Yes (Hour) | DC 24V | 2XG 1/4 | 540 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212PDTGLCM..D24 | 6 | DT | yes | 2x 6.0 ml/min | Yes (Minute) | DC 24V | 2XG 1/4 | 540 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212PDTGNCM..D24 | 6 | DT | / | 2x 6.0 ml/min | Yes (Minute) | DC 24V | 2XG 1/4 | 540 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212PDTGNCH..D24 | 6 | DT | / | 2x 6.0 ml/min | Yes (Hour) | DC 24V | 2XG 1/4 | 540 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212PDGLCM..D24 | 6 | D | yes | 2x 6.0 ml/min | Yes (Minute) | DC 24V | 2XG 1/4 | 520 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212PDGLCH..D24 | 6 | D | yes | 2x 6.0 ml/min | Yes (Hour) | DC 24V | 2XG 1/4 | 520 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212PDGNCM..D24 | 6 | D | / | 2x 6.0 ml/min | Yes (Minute) | DC 24V | 2XG 1/4 | 520 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212PDGNCH..D24 | 6 | D | / | 2x 6.0 ml/min | Yes (Hour) | DC 24V | 2XG 1/4 | 520 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212DTGNCH..D24 | 4 | DT | / | 2x 6.0 ml/min | Yes (Hour) | DC 24V | 2XG 1/4 | 450 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212DGLCM..D24 | 4 | D | yes | 2x 6.0 ml/min | Yes (Minute) | DC 24V | 2XG 1/4 | 430 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212DGLCH..D24 | 4 | D | yes | 2x 6.0 ml/min | Yes (Hour) | DC 24V | 2XG 1/4 | 430 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212DGNCM..D24 | 4 | D | / | 2x 6.0 ml/min | Yes (Minute) | DC 24V | 2XG 1/4 | 430 | 250 | 350 | 200 | 90 | 4 x Ø9 |
| LEP212DGNCH..D24 | 4 | D | / | 2x 6.0 ml/min | Yes (Hour) | DC 24V | 2XG 1/4 | 430 | 250 | 350 | 200 | 90 | 4 x Ø9 |
