LEP21X Single-Line Lubrication Pump
results
| P/N | Tank capacity (L) | Pump type | Low level monitoring | Controller | Power supply | Pump element | Pump outlet | H (mm) | W (mm) | L (mm) | K (mm) | Ød (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| User manual- LUBElite single-line | 8 | M | / | Yes (Hour) | DC 24V | 1 x 6.0 ml/min | G 1/4 | 525 | 250 | 380 | 200 | 2 x Ø9 |
| Product catalog - LUBElite single-line | 8 | M | / | Yes (Hour) | DC 24V | 1 x 6.0 ml/min | G 1/4 | 525 | 250 | 380 | 200 | 2 x Ø9 |
| LEP2110MTGLCM..A23 | 10 | MT | yes | Yes (Minute) | AC 230V/50Hz | 1 x 6.0 ml/min | G 1/4 | 575 | 250 | 380 | 200 | 2 x Ø9 |
| LEP2110MTGLCH..A23 | 10 | MT | yes | Yes (Hour) | AC 230V/50Hz | 1 x 6.0 ml/min | G 1/4 | 575 | 250 | 380 | 200 | 2 x Ø9 |
| LEP2110MTGNCM..A23 | 10 | MT | / | Yes (Minute) | AC 230V/50Hz | 1 x 6.0 ml/min | G 1/4 | 575 | 250 | 380 | 200 | 2 x Ø9 |
| LEP2110MTGNCH..A23 | 10 | MT | / | Yes (Hour) | AC 230V/50Hz | 1 x 6.0 ml/min | G 1/4 | 575 | 250 | 380 | 200 | 2 x Ø9 |
| LEP2110MGLCH..A23 | 10 | M | yes | Yes (Hour) | AC 230V/50Hz | 1 x 6.0 ml/min | G 1/4 | 555 | 250 | 380 | 200 | 2 x Ø9 |
| LEP2110MGLCM..A23 | 10 | M | yes | Yes (Minute) | AC 230V/50Hz | 1 x 6.0 ml/min | G 1/4 | 555 | 250 | 380 | 200 | 2 x Ø9 |
| LEP2110MGNCM..A23 | 10 | M | / | Yes (Minute) | AC 230V/50Hz | 1 x 6.0 ml/min | G 1/4 | 555 | 250 | 380 | 200 | 2 x Ø9 |
| LEP2110MGNCH..A23 | 10 | M | / | Yes (Hour) | AC 230V/50Hz | 1 x 6.0 ml/min | G 1/4 | 555 | 250 | 380 | 200 | 2 x Ø9 |
| LEP2110MTGLCM..D24 | 10 | MT | yes | Yes (Minute) | DC 24V | 1 x 6.0 ml/min | G 1/4 | 575 | 250 | 380 | 200 | 2 x Ø9 |
| LEP2110MTGLCH..D24 | 10 | MT | yes | Yes (Hour) | DC 24V | 1 x 6.0 ml/min | G 1/4 | 575 | 250 | 380 | 200 | 2 x Ø9 |
| LEP2110MTGNCM..D24 | 10 | MT | / | Yes (Minute) | DC 24V | 1 x 6.0 ml/min | G 1/4 | 575 | 250 | 380 | 200 | 2 x Ø9 |
| LEP2110MTGNCH..D24 | 10 | MT | / | Yes (Hour) | DC 24V | 1 x 6.0 ml/min | G 1/4 | 575 | 250 | 380 | 200 | 2 x Ø9 |
| LEP2110MGLCH..D24 | 10 | M | yes | Yes (Hour) | DC 24V | 1 x 6.0 ml/min | G 1/4 | 555 | 250 | 380 | 200 | 2 x Ø9 |
| LEP2110MGLCM..D24 | 10 | M | yes | Yes (Minute) | DC 24V | 1 x 6.0 ml/min | G 1/4 | 555 | 250 | 380 | 200 | 2 x Ø9 |
| LEP2110MGNCM..D24 | 10 | M | / | Yes (Minute) | DC 24V | 1 x 6.0 ml/min | G 1/4 | 555 | 250 | 380 | 200 | 2 x Ø9 |
| LEP2110MGNCH..D24 | 10 | M | / | Yes (Hour) | DC 24V | 1 x 6.0 ml/min | G 1/4 | 555 | 250 | 380 | 200 | 2 x Ø9 |
| LEP213MTGLCM..A23 | 8 | MT | yes | Yes (Minute) | AC 230V/50Hz | 1 x 6.0 ml/min | G 1/4 | 545 | 250 | 380 | 200 | 2 x Ø9 |
| LEP213MTGLCH..A23 | 8 | MT | yes | Yes (Hour) | AC 230V/50Hz | 1 x 6.0 ml/min | G 1/4 | 545 | 250 | 380 | 200 | 2 x Ø9 |
| LEP213MTGNCM..A23 | 8 | MT | / | Yes (Minute) | AC 230V/50Hz | 1 x 6.0 ml/min | G 1/4 | 545 | 250 | 380 | 200 | 2 x Ø9 |
| LEP213MTGNCH..A23 | 8 | MT | / | Yes (Hour) | AC 230V/50Hz | 1 x 6.0 ml/min | G 1/4 | 545 | 250 | 380 | 200 | 2 x Ø9 |
| LEP213MGLCH..A23 | 8 | M | yes | Yes (Hour) | AC 230V/50Hz | 1 x 6.0 ml/min | G 1/4 | 525 | 250 | 380 | 200 | 2 x Ø9 |
| LEP213MGLCM..A23 | 8 | M | yes | Yes (Minute) | AC 230V/50Hz | 1 x 6.0 ml/min | G 1/4 | 525 | 250 | 380 | 200 | 2 x Ø9 |
| LEP213MGNCM..A23 | 8 | M | / | Yes (Minute) | AC 230V/50Hz | 1 x 6.0 ml/min | G 1/4 | 525 | 250 | 380 | 200 | 2 x Ø9 |
| LEP213MGNCH..A23 | 8 | M | / | Yes (Hour) | AC 230V/50Hz | 1 x 6.0 ml/min | G 1/4 | 525 | 250 | 380 | 200 | 2 x Ø9 |
| LEP213MTGNCM..D24 | 8 | MT | / | Yes (Minute) | DC 24V | 1 x 6.0 ml/min | G 1/4 | 545 | 250 | 380 | 200 | 2 x Ø9 |
| LEP213MTGLCM..D24 | 8 | MT | yes | Yes (Minute) | DC 24V | 1 x 6.0 ml/min | G 1/4 | 545 | 250 | 380 | 200 | 2 x Ø9 |
| LEP213MTGLCH..D24 | 8 | MT | yes | Yes (Hour) | DC 24V | 1 x 6.0 ml/min | G 1/4 | 545 | 250 | 380 | 200 | 2 x Ø9 |
| LEP213MTGNCH..D24 | 8 | MT | / | Yes (Hour) | DC 24V | 1 x 6.0 ml/min | G 1/4 | 545 | 250 | 380 | 200 | 2 x Ø9 |
| LEP213MGLCH..D24 | 8 | M | yes | Yes (Hour) | DC 24V | 1 x 6.0 ml/min | G 1/4 | 525 | 250 | 380 | 200 | 2 x Ø9 |
| LEP213MGLCM..D24 | 8 | M | yes | Yes (Minute) | DC 24V | 1 x 6.0 ml/min | G 1/4 | 525 | 250 | 380 | 200 | 2 x Ø9 |
| LEP213MGNCM..D24 | 8 | M | / | Yes (Minute) | DC 24V | 1 x 6.0 ml/min | G 1/4 | 525 | 250 | 380 | 200 | 2 x Ø9 |
| LEP213MGNCH..D24 | 8 | M | / | Yes (Hour) | DC 24V | 1 x 6.0 ml/min | G 1/4 | 525 | 250 | 380 | 200 | 2 x Ø9 |
