HXP
results
| P/N | Displacement (cm3/min) | Tank capacity (kg) | Low level monitoring | Gearbox ratio | Power supply | Power cable | Pressure switch | Controller | Signal cable | Outlet thread | H (mm) | W (mm) | L (mm) | Ød1 (mm) | Ød2 (mm) | Ød3 (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| HXP55E…HD | 444 | 55 | Electric level sensor | / | Hydraulic oil | / | / | / | / | G 1/4 | 1045 | 572 | 457 | 425 | 394 | 4 x Ø15 |
| HXP55L…HD | 444 | 55 | Visual indicator | / | Hydraulic oil | / | / | / | / | G 1/4 | 1045 | 572 | 457 | 425 | 394 | 4x Ø15 |
| HXP40E…HD | 444 | 40 | Electric level sensor | / | Hydraulic oil | / | / | / | / | G 1/4 | 1045 | 552 | 437 | 385 | 352 | 6 x Ø11 |
| HXP40L…HD | 444 | 40 | Visual indicator | / | Hydraulic oil | / | / | / | / | G 1/4 | 1045 | 552 | 435 | 385 | 352 | 6 x Ø11 |
| HXP28E…HD | 444 | 28 | Electric level sensor | / | Hydraulic oil | / | / | / | / | G 1/4 | 845 | 551 | 437 | 385 | 352 | 6 x Ø11 |
| HXP28L…HD | 444 | 28 | Visual indicator | / | Hydraulic oil | / | / | / | / | G 1/4 | 845 | 552 | 437 | 385 | 352 | 6 x Ø11 |
| HXP55EPSCH…R1D24 | 88 | 55 | Electric level sensor | 24:1 | DC 24V | / | Yes | Yes (Hour) | / | G 1/4 | 920 | 470 | 552 | 425 | 394 | 4x Ø15 |
| HXP55EPSCM…R1D24 | 88 | 55 | Electric level sensor | 24:1 | DC 24V | / | Yes | Yes (Minute) | / | G 1/4 | 920 | 470 | 552 | 425 | 394 | 4x Ø15 |
| HXP55ECM…R1D24 | 88 | 55 | Electric level sensor | 24:1 | DC 24V | / | / | Yes (Minute) | / | G 1/4 | 920 | 470 | 552 | 425 | 394 | 4x Ø15 |
| HXP55ECH…R1D24 | 88 | 55 | Electric level sensor | 24:1 | DC 24V | / | / | Yes (Hour) | / | G 1/4 | 920 | 470 | 550 | 425 | 394 | 4x Ø15 |
| HXP55EPS…R1D24 | 88 | 55 | Electric level sensor | 24:1 | DC 24V | / | Yes | / | / | G 1/4 | 920 | 470 | - | 425 | 352 | 6x Ø11 |
| HXP55E…R1D24 | 88 | 55 | Electric level sensor | 24:1 | DC 24V | / | / | / | / | G 1/4 | 920 | 470 | - | 425 | 394 | 6x Ø11 |
| HXP55LPSCM…R1D24 | 88 | 55 | Visual indicator | 24:1 | DC 24V | / | Yes | Yes (Minute) | / | G 1/4 | 920 | 470 | 552 | 425 | 394 | 4x Ø15 |
| HXP55LPSCH…R1D24 | 88 | 55 | Visual indicator | 24:1 | DC 24V | / | Yes | Yes (Hour) | / | G 1/4 | 920 | 470 | 552 | 425 | 394 | 4x Ø15 |
| HXP55LCM…R1D24 | 88 | 55 | Visual indicator | 24:1 | DC 24V | / | / | Yes (Minute) | / | G 1/4 | 920 | 470 | 552 | 425 | 394 | 4x Ø15 |
| HXP55LCH…R1D24 | 88 | 55 | Visual indicator | 24:1 | DC 24V | / | / | Yes (Hour) | / | G 1/4 | 920 | 470 | 552 | 425 | 394 | 4x Ø15 |
| HXP55LPS…R1D24 | 88 | 55 | Visual indicator | 24:1 | DC 24V | / | Yes | / | / | G 1/4 | 920 | 470 | - | 425 | 394 | 6x Ø11 |
| HXP55L…R1D24 | 88 | 55 | Visual indicator | 24:1 | DC 24V | / | / | / | / | G 1/4 | 920 | 470 | - | 425 | 352 | 6x Ø11 |
| HXP40EPSCM…R1D24 | 88 | 40 | Electric level sensor | 24:1 | DC 24V | / | Yes | Yes (Minute) | / | G 1/4 | 920 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP40EPSCH…R1D24 | 88 | 40 | Electric level sensor | 24:1 | DC 24V | / | Yes | Yes (Hour) | / | G 1/4 | 920 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP40ECM…R1D24 | 88 | 40 | Electric level sensor | 24:1 | DC 24V | / | / | Yes (Minute) | / | G 1/4 | 920 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP40ECH…R1D24 | 88 | 40 | Electric level sensor | 24:1 | DC 24V | / | / | Yes (Hour) | / | G 1/4 | 920 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP40EPS…R1D24 | 88 | 40 | Electric level sensor | 24:1 | DC 24V | / | Yes | / | / | G 1/4 | 920 | 443 | - | 385 | 352 | 6 x Ø11 |
| HXP40E…R1D24 | 88 | 40 | Electric level sensor | 24:1 | DC 24V | / | / | / | / | G 1/4 | 920 | 445 | - | 385 | 352 | 6 x Ø11 |
| HXP40LPSCH…R1D24 | 88 | 40 | Visual indicator | 24:1 | DC 24V | / | Yes | Yes (Hour) | / | G 1/4 | 920 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP40LPSCM…R1D24 | 88 | 40 | Visual indicator | 24:1 | DC 24V | / | Yes | Yes (Minute) | / | G 1/4 | 920 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP40LCM…R1D24 | 88 | 40 | Visual indicator | 24:1 | DC 24V | / | / | Yes (Minute) | / | G 1/4 | 920 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP40LCH…R1D24 | 88 | 40 | Visual indicator | 24:1 | DC 24V | / | / | Yes (Hour) | / | G 1/4 | 920 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP40LPS…R1D24 | 88 | 40 | Visual indicator | 24:1 | DC 24V | / | Yes | / | / | G 1/4 | 920 | 445 | - | 385 | 352 | 6 x Ø11 |
| HXP40L…R1D24 | 88 | 40 | Visual indicator | 24:1 | DC 24V | / | / | / | / | G 1/4 | 920 | 443 | - | 385 | 352 | 6 x Ø11 |
| HXP28EPSCM…R1D24 | 88 | 28 | Electric level sensor | 24:1 | DC 24V | / | Yes | Yes (Minute) | / | G 1/4 | 720 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP28EPSCH…R1D24 | 88 | 28 | Electric level sensor | 24:1 | DC 24V | / | Yes | Yes (Hour) | / | G 1/4 | 720 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP28ECM…R1D24 | 88 | 28 | Electric level sensor | 24:1 | DC 24V | / | / | Yes (Minute) | / | G 1/4 | 720 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP28ECH…R1D24 | 88 | 28 | Electric level sensor | 24:1 | DC 24V | / | / | Yes (Hour) | / | G 1/4 | 720 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP28EPS…R1D24 | 88 | 28 | Electric level sensor | 24:1 | DC 24V | / | Yes | / | / | G 1/4 | 720 | 445 | - | 385 | 352 | 6 x Ø11 |
| HXP28E…R1D24 | 88 | 28 | Electric level sensor | 24:1 | DC 24V | / | / | / | / | G 1/4 | 720 | 445 | - | 385 | 352 | 6 x Ø11 |
| HXP28LPSCH…R1D24 | 88 | 28 | Visual indicator | 24:1 | DC 24V | / | Yes | Yes (Hour) | / | G 1/4 | 720 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP28LPSCM…R1D24 | 88 | 28 | Visual indicator | 24:1 | DC 24V | / | Yes | Yes (Minute) | / | G 1/4 | 720 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP28LCM…R1D24 | 88 | 28 | Visual indicator | 24:1 | DC 24V | / | / | Yes (Minute) | / | G 1/4 | 720 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP28LCH…R1D24 | 88 | 28 | Visual indicator | 24:1 | DC 24V | / | / | Yes (Hour) | / | G 1/4 | 720 | 445 | 512 | 385 | 352 | 6 x Ø11 |
| HXP28LPS…R1D24 | 88 | 28 | Visual indicator | 24:1 | DC 24V | / | Yes | / | / | G 1/4 | 720 | 445 | - | 385 | 352 | 6 x Ø11 |
| HXP28L…R1D24 | 88 | 28 | Visual indicator | 24:1 | DC 24V | / | / | / | / | G 1/4 | 720 | 445 | - | 385 | 352 | 6 x Ø11 |
